SONORA-5AIPN | Active IP Speaker with Passive Output

The versatile powerhouse of the SONORA IP series, featuring a dual-channel amplifier to drive both itself and a secondary passive speaker.

The SONORA-5AIPN is a high-efficiency active IP speaker that serves as the perfect building block for distributed audio networks. While it shares the premium acoustic DNA of the SONORA family, the "N" model is specifically engineered to be a cost-effective leader: its built-in Class D amplifier provides a dedicated output to power an additional passive speaker (such as the SONORA-5N). This "Master-Slave" configuration allows you to cover double the area with only a single IP address and one network drop.

Key Features

Dual-Channel Amplification: Integrated IP client with a 20W + 20W RMS amplifier, designed to power the internal driver plus one external passive speaker.

Cost-Efficient Coverage: Reduce network infrastructure costs by covering medium-sized rooms with one active IP unit and one affordable passive unit.

Premium Acoustics: Equipped with a 5 ¼" polypropylene woofer and a 1" tweeter for high-fidelity music and clear, intelligible paging.

Robust Weatherproofing: Boasts an IP-66 rating and an aluminum grille, making it ideal for outdoor installations, damp environments, or coastal areas.

AIP Integration: Fully compatible with Fonestar’s AIP-Management software for scheduling, zone grouping, and real-time streaming.

Why Choose the SONORA-5AIPN?

Maximum Efficiency

The SONORA-5AIPN is the smartest choice for budget-conscious projects that refuse to compromise on quality. By driving two speakers from a single IP node, you save on network switch ports, cabling time, and software licensing fees while maintaining full stereo or mono coverage.

Built for the Elements

Don't let the sleek design fool you. This speaker is built to survive. With a treatment against UV rays, stainless steel screws, and an IP-66 rating, it is perfectly at home on an outdoor terrace, in a warehouse, or at a sports facility.

Flexible Power Logistics

While it supports PoE for simple low-power installations, connecting a local 12V DC power supply unlocks the full 40W total output, providing enough "punch" for noisier commercial environments or larger open spaces.
