Fonestar SONORA-3TB 3" 12W 100V line transformer and low impedance wall speaker
✓ Available to order
Express delivery: order before 14:00 (Mon–Fri) and we'll dispatch that evening for next working day delivery.
Free delivery on orders over £100: allow up to 7 working days. Weekend orders are processed from Monday.
- 100 V line or 8 Ω
- 12 W RMS (20 W max.)
- IP66 outdoor rated
- 130 Hz – 20 kHz
Talk to our team: 01284 652 949
Expert advice on choosing and designing your system.
Talk to our team: sales@commercial-audio.co.uk
Email your quantities or project details and we'll send you a tailored quote.
3-year manufacturer's warranty
UK installer network
We can quote for installation through our UK installer network.
Sound reinforcement loudspeaker with 100 V line transformer and low impedance.
Based on our extensive experience in the sound sector, FONESTAR has created SONORA.
SONORA is a series of loudspeakers especially designed for PA and background sound applications.
Its excellent finish and elegant design allow perfect integration in any space.
In addition, SONORA delivers high sound quality with clear, distortion-free sound.
They include all the necessary accessories for quick and easy installation: swivel mount and screws.
For public address and ambient sound applications in public places such as restaurants, cafés, supermarkets, shopping centres, etc.
| Power | 20 W max., 12 W RMS |
|---|---|
| Driver | 1 x 3" polypropylene woofer |
| Frequency response | 130 – 20,000 Hz (-10 dB) |
| 100 V taps | 12 W (833 Ω) / 6 W (1,666 Ω) / 3 W (3,333 Ω) / 1.5 W (6,666 Ω) |
| 70 V taps | 6 W (816 Ω) / 3 W (1,633 Ω) / 1.5 W (3,266 Ω) / 0.75 W (6,533 Ω) |
| Low impedance | 8 Ω (12 W RMS) |
| Sensitivity | 84 dB @ 1 W / 1 m |
| Max. SPL | 94 dB @ max. W / 1 m |
| Coverage (H/V, -6 dB) | 270° @ 500 Hz, 180° @ 1 kHz, 120° @ 2 kHz, 100° @ 4 kHz |
| Protection | IP66 (EN 60529); salt mist tested to IEC 60068-2-11 |
| Materials | UV-resistant ABS; powder-coated aluminium mesh grille; A2 stainless steel screws |
| Selector | Power selector for high Z (100 V) and low Z (8 Ω) |
| Connectors | Euroblock in and out, 0.25 – 2.5 mm² cable |
| Operating temperature | -10 °C to 60 °C |
| Colour | White (RAL 9003) |
| Dimensions | 97 x 110 x 107 mm (150 mm deep with mount); wall plate 67 x 71 mm |
| Weight | 0.7 kg |
| Mount | Adjustable bracket included, H ±30°, V +15° / -45° |
