Monacor PA-9100D 1000W mono mixer amplifier
✓ Available to order
Express delivery: order before 15:00 (Mon–Fri) and we'll dispatch that evening for a next-day service.
Free delivery: allow up to 7 working days. Standard delivery (£6.50 inc VAT): 2–4 working days. Weekend orders are processed from Monday.
- 1,000 W
- 20-20,000 Hz
- 5 channels
- Inputs: 3 mV (mic)
Talk to our team: 01284 652 949
Expert advice on choosing and designing your system.
Free delivery option
Express next-day service if ordered before 15:00 (Mon–Fri).
3-year manufacturer's warranty
Our products come with a 3-year manufacturer's warranty as standard.
UK installer network
We can quote for installation through our UK installer network.
**Mono Class D PA Mixing Amplifier**
- Powerful output of 1 x 1,000 W
- Features a Class D design with a high-quality PASCAL amplifier module
- Designed for energy efficiency, providing exceptional performance with minimal energy use
- Compact switch-mode power supply contributes to its lightweight construction
- Operates silently due to a fanless cooling system
- Equipped with 4 balanced mic/line inputs for versatility
- Mic 1 includes a priority circuit with automatic talkover for seamless transitions
- Additional screw terminal connection available for a desktop microphone
- Includes 1 aux input for supplementary audio sources
- Speaker outputs are provided via secure screw contacts
- Offers a line output for connecting to external devices
- Insert facility available for effects units, equalizers, and feedback controllers
- Features input and output level controls for easy adjustment
- 2-way tone control enhances output audio quality
- Provides 48 V phantom power for each microphone input, with individual activation
- Limiter switch for 4 Ω/8 Ω/100 V operation
- Comes with removable mounting brackets for convenient installation
| Peak output power | 1,000 W |
|---|---|
| Power rating | 1,000 W |
| Power rating at 4 Ω | 900 W |
| Power rating at 8 Ω | 1,000 W |
| Power rating at 100 V | 1,000 W@9.2 Ω |
| Output impedance | 4-8 Ω |
| Channels | 5 |
| Inputs | 3 mV (mic),; 200 mV (line),; 140 mV (aux) |
| Frequency range | 20-20,000 Hz |
| Integrated limiter | yes |
| Equalizer bass | ± 10 dB/100 Hz |
| Equalizer treble | ± 10 dB/10 kHz |
| S/N ratio | > 80 dB |
| THD | < 0.1% |
| Phantom power | 48 V |
| Power supply | ˜ 90-230 V/50-60 Hz/1,100 VA |
| Mains voltage | ~ 90-230 V |
| Mains frequency | 50-60 Hz |
| Power consumption, operation | 1,030 VA |
| Admiss. ambient temp. | 0-40 °C |
| Width | 482 mm |
| Height | 88 mm |
| Depth | 275 mm |
| Rack units, RU | 2 |
| Weight | 5.6 kg |
| Connections | 4 x XLR (mic/line),; 1 x RCA L/R (aux),; screw contacts (speakers) |
| Packaging dimensions (W x H x L) | 0.5 x 0.13 x 0.36 m |
| Gross weight | 6.6 kg |
| Net weight | 5.6 kg |
